Single & Double Pass Transmission Fiber Optic Probes


Single & Double Pass Transmission Fiber Optic Probes

$4,799.00

Transmission/Absorbance probes for use in demanding industrial environments. Contains SMA-905 fiber optic connections, which provide the light source, The Single Pass version is for use in high concentration samples while the Double Pass is for use in low concentration. Comes standard with UV Quartz optics.

Variation:
Quantity:
Add To Cart

Standard Specifications:

SINGLE PASS TRANSMISSION PROBE

  • Lightpath: 1-8mm

  • Probe length: 220mm

  • Probe diameter: 12mm

  • Probe material: 316 Stainless Steel

  • Optics material: UV Quartz (190-2,500nm)

  • Seal material: Viton

  • Temperature range: -5ºC - 204ºC

DOUBLE PASS TRANSMISSION PROBE

  • Lightpaths: 5, 10 or 20mm

  • Probe length: 225mm

  • Probe diameter: 12mm

  • Probe material: 316 Stainless Steel

  • Optics material: UV Quartz (190-2,500nm)

  • Seal material: Viton

  • Temperature range: -5ºC - 204ºC
